Pedigreed shredders from the ‘80s, Pro-Mod San Dimas® guitars are packed with high-speed playability and innovative design elements that epitomize Charvel’s definitive combination of time-honored style and modern features, power and performance.
The Pro-Mod San Dimas Style 2 HH FR M QM offers an alder body with quilt maple top and a two-piece bolt-on maple neck with graphite reinforcement rods for rock-solid stability, despite the ravages of the road and climate. Engineered for effortlessly nimble and highly-expressive playing, this guitar has a speed neck profile, a 12”-16” compound radius maple fingerboard with hand-rubbed urethane gel back finish, 22 jumbo frets, black dot inlays and a convenient thumbwheel truss rod butt-adjust for easy access.
Hot-rodded for unparalleled performance and versatile sound, this instrument is equipped with a high-output Seymour Duncan® JB TB-4 humbucking bridge pickup and a warm, fat Seymour Duncan® ’59 SH-1N humbucking neck pickup for killer tone, controlled with a three-way blade switch. The volume control hides a push/pull coil split for even more highly useful tonal variations—ideal for everything from a biting lead sound to thick, chunky rhythm work, while the No-Load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound, letting the full natural voice of the guitar shine through.
br/>
Scream or rumble with a Floyd Rose® double-locking recessed tremolo and locking nut without sacrificing tuning stability or the pinpoint intonation.
|
|---|
| Body Shape: | Style 2 |
| Body Material: | Alder |
| Body Finish: | Gloss |
| Neck |
| Scale Length: | 25.5" (64.8 cm) |
| Fingerboard Radius: | 12" to 16" Compound Radius (304.8 mm to 406.4 mm) |
| Fret Size: | Jumbo |
| String Nut: | Floyd Rose® Locking |
| Nut Width: | 1.6875" (42.8 mm) |
| Headstock: | Standard Stratocaster® |
| Neck Plate: | NA |
| Neck Finish: | Hand-Rubbed Urethane Gel |
| Fingerboard: | Maple |
| Position Inlays: | Black Dot |
| Electronics |
| Bridge Pickup: | Seymour Duncan® JB™ TB4 Humbucking |
| Neck Pickup: | Seymour Duncan® '59™ SH1N Humbucking |
| Controls: | Volume (Push/Pull Coil Split), No-Load Tone Circuit |
| Pickup Switching: | 3-Position Blade: Position 1: Bridge Pickup, Position 2: Both inner coils, Position 3:Neck Pickup, (split engaged) Position 1: Bridge outer coil, Position 2: Both outer coils, Position 3: Neck outer coil |
| Pickup Configuration: | HH |
| Hardware |
| Bridge: | Floyd Rose® Double Locking Tremolo |
| Tuning Machines: | Charvel® Branded Die-Cast |
| Orientation: | Right-Hand |
| Pickguard: | None |
| Control Knobs: | Knurled Flat-Top |
