Serial Number: MC160788 & MC160866
Weight: 8.4 lbs
The Charvel® Pro-Mod San Dimas Style 1, the ideal instrument for dazzling high speed playing, was born and raised in this sunny environment. With scorching sound, stunning quilt-top style and grin-inducing playing feel & performance, this guitar was meant to be onstage.
A top-notch performer that’s tweaked with the features modern players need, this axe sports hot-rodded high-output SD JB™ and SD '59 humbucking pickups directly mounted to the body that crank out high octane rock ‘n’ roll tone with plenty of sweet overtones. The volume control conceals a push/pull coil split to have even more tonal variations on tap while the No-Load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound, letting the full natural voice of the guitar shine through. Dive to rumbling depths or add a well-placed rising harmonic without sacrificing your tuning with the Floyd Rose® FRT-O1000 double-locking recessed trem & FRT-O1000 locking nut—simultaneously grooving on the laser-accurate intonation. The two-piece maple neck hosts 22 jumbo frets along with a pair of graphite reinforcement rods to resist bending & warping under environmental stresses. The speed neck profile is designed for lightning fast playing & completely unhindered position shifts while the comfortably rolled fingerboard edges provide the broken-in feel of an instrument with plenty of playing miles on it, & plenty more to go.
A Charvel neck plate, branded die-cast tuning machines & standard strap buttons complete the package, topped off with a spotlight-ready finish that shrugs off the rigors of the road.
| | |
|---|
| Model Name | | Pro Mod San Dimas® Style 1 |
| Series | | Pro Mod |
| Color | | Trans Black Burst |
| Body Shape | | San Dimas® |
| Body Material | | Alder with Quilt Maple Top |
| Body Finish | | Gloss Poly |
| Neck Material | | 2-Piece Maple with Graphite reinforcement |
| Neck Shape | | Speed Neck with rolled fingerboard edges |
| Scale Length | | 25.5" (64.8 cm) |
| Fingerboard Radius | | 12" to 16" Compound Radius (304.8 mm to 406.4 mm) |
| Number of Frets | | 22 |
| Fret Size | | Jumbo |
| String Nut | | Floyd Rose® FRT |
| Nut Width | | 1.6875" (43 mm) |
| Truss Rod Nut | | Heel-Mounted Spoke Wheel Adjustment |
| Neck Plate | | Charvel® MU |
| Neck Finish | | Hand-Rubbed Urethane |
| Fingerboard | | Maple |
| Position Inlays | | Black Dot |
| Pickups | | Direct Mount Seymour Duncan® JB™ Hum |
| Controls | | Volume with push/pull coil split, No-Load Tone Control |
| Pickup Switching | | 3-Position Blade: Position 1: Bridge Pickup, Position 2: Both inner coils, Position 3:Neck Pickup, (split engaged) Position 1: Bridge outer coil, Position 2: Both outer coils, Position 3: Neck outer coil |
| Pickup Configuration | | HH |
| Bridge | | Floyd Rose® FRT-O2000 Double-Locking Trem (Recessed) |
| Tuning Machines | | Die-Cast |
| Control Knobs | | Knurled Flat-Top |
