Serial Number: EVH021129
Loaded with pure EVH sound and power, the new EVH 50-Watt Head is a scaled-down version of its acclaimed 100-watt big brother—the mighty 5150III head—with many of the same great features. Its smaller size and portability make it a perfect amp for players who want arena volume, tone and performance in a compact package. It pairs perfectly with the new EVH 2×12 and 1×12 cabinets, in addition to the current EVH 4×12 cabinet.
It’s a three-channel amp; channels one and two share EQ, with gain, low, mid, high and volume controls; channel three has gain, low, mid, high, volume and master presence and resonance controls. Other features include selectable impedance (4, 8 or 16 ohms), dual parallel speaker output jacks, effects loop, headphone jack, line out and black hardware. Included four-button footswitch has 1/4” input jack; also accommodates MIDI footswitching. Available in Black and Ivory textured vinyl covering with black EVH-striped grille.
| | |
|---|
| Model Name | | 5150III® 50W Head |
| Series | | 5150III® |
| Amplifier Type | | Tube |
| Wattage | | 50 Watts |
| Effects Loop | | 1/4" - (Send/Return) |
| Inputs | | One - 1/4" |
| Headphone Jack | | 1/4" Stereo |
| Line Out | | One - (1/4") |
| Extension Speaker Jack | | Two 1/4" Parallel |
| Channels | | Three - (Clean, Crunch, and Lead) |
| Controls | | Master Presence, Channel 1 and 2: Gain, Low, Mid, High, Volume; Channel 3: Gain, Low, Mid, High, Volume, Master Resonance Control (rear panel) |
| Cabinet Material | | 7-Ply 5/8" Birch Plywood |
| Preamp Tubes | | 7 JJ ECC83 (12AX7) |
| Power Tubes | | 2 JJ 6L6 |
| Output Impedance | | 4, 8 or 16 ohms (Selectable) |
| Footswitch | | 4-Button Footswitch Included |
| Unique Features | | 4-button footswitch with 1/4" cable input with ultra fast switching, MIDI input that can be used to control channels and effects loop with virtually any MIDI device, 3 foot heavy duty speaker cable |
| Pilot Light Jewel | | Red LED Jewel |
| Front Panel | | Black EVH Striped Steel |
| Cover/Grill Cloth | | Black or Ivory Textured Vinyl Covering with Black EVH Striped Steel Grille |
| Handle | | Molded Plastic Strap with Nickel-Plated Caps |
| Height | | 8.6" |
| Length | | 12" |
| Width | | 20" |
| Weight | | 35 lbs |
