Serial Number: JMM1510236
Weight: 7.4 lbs
Misha Mansoor is acclaimed for his masterful guitar work in fashioning the progressive metal of Periphery. Now, the esteemed Djent-leman himself and Jackson have collaborated closely on the Misha Mansoor Juggernaut HT7, a brand-new seven-string model like nothing else Jackson has ever seen—or heard—before. The instrument is crafted with a distinctive Jackson body shape inspired by the Dinky™, with sleekly scalloped horns, a comfortably contoured neck heel and a gorgeous quilt maple top on trans-finish models. The bolt-on quartersawn maple neck is sculpted with Mansoor’s own custom profile, and features graphite reinforcement, ivoroid binding and heel-end thumbwheel truss rod adjustment.
The 20-radius ebony fingerboard is crafted with 24 stainless steel jumbo frets, piranha inlays and Luminlay fluorescent side dots. The guitar’s tonally versatile sound comes from Mansoor’s dual direct-mount signature Bare Knuckle "Juggernaut" humbucking pickups with black covers, five-way switching and a pushpull (on/off) master tone knob. Other premium features include a Jackson AT1 headstock with Hipshot open-gear locking tuners (three on one side, four on the other), Hipshot hard-tail seven-string bridge, single volume control knob, black hardware and more.
| | |
|---|
| Model Name | | Misha Mansoor Juggernaut HT7, Ebony Fingerboard, Silver Sparkle Burst |
| Color | | Silver Sparkle Burst |
| Body Material | | Baked Basswood |
| Body Finish | | Satin Urethane |
| Body Shape | | Juggernaut |
| Body Binding | | Wood |
| Neck Material | | 1-Piece Bolt-On Quartersawn Maple with Graphite Reinforcement and Scarf Joint |
| Neck Finish | | Hand-Rubbed Urethane Gel |
| Neck Shape | | 3rd Fret: 0.790", 12th Fret: 0.850" |
| Scale Length | | 26.5" (673 mm) |
| Fingerboard | | Ebony |
| Fingerboard Radius | | 20" (508 mm) |
| Number of Frets | | 24 |
| Fret Size | | Jumbo |
| String Nut | | Graph Tech® NuBone™ |
| Nut Width | | 1.75" (44.45 mm) |
| Position Inlays | | Piranha Tooth (Small Shark Fin) |
| Truss Rod Nut | | Heel-Mounted Spoke Wheel Adjustment |
| Headstock | | Jackson® 4+3 AT-1 |
| Bridge Pickup | | Direct Mount Bareknuckle Pickups, Juggernaut 7-String Humbucker, Black Covers with Black Hex Pole Pieces |
| Neck Pickup | | Direct Mount Bareknuckle Pickups, Juggernaut 7-String Humbucker, Black Covers with Black Hex Pole Pieces |
| Controls | | Master Volume, Master Tone (with Push/Pull Coil Select Feature) |
| Pickup Switching | | 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Two Inside Single Coils, Position 3. Both Full Humbucking Pickups, Position 4. Outer Neck Single Coil, Position 5. Full Neck Pickup |
| Pickup Configuration | | HH |
| Bridge | | Hipshot 7 - Fixed .175 |
| Hardware Finish | | Black |
| Tuning Machines | | Hipshot Open-Gear Locking |
| Pickguard | | None |
| Pickup Covers | | Black |
| Switch Tips | | Black |
